HETA

HETA is a unique, original design, whose massiveness gives buildings the character of monumental modernity.

ASK FOR A QUOTE CONTACT YOUR ADVISOR BIM LIBRARY

ASK FOR PRODUCT

EASY LINK

A proprietary solution that makes the sheets fit together like never before.

A proprietary solution that makes the sheets fit together like never before. A special cut and profiling of the outermost embossing allow perfect fitting of the sheets at the point of contact.

3D shaped cut

HETA roof tiles are waveshape cut so that the horizontal joints of the sheets are less visible.

Installation holes

Enable the sheets to be fitted together quickly and tightly.

Steel roof tiles HETA with ribs with the height of 30 mm and 40 mm have installation holes on the vertical ribs.

Metal sheets cut to dimension

Perfectly matched to a specific roof design

Metal sheets cut to dimension are perfectly matched to a specific roof design.

BIM Library

The following product can be found in the BP2 BIM library for architects and designers.

Are you working on a roof design and looking for the best solution that would meet all your requirements? Let us provide you with BP2 Libraries to design using BIM modelling. Thanks to precise models, you will be able to prepare a complete 3D detailed design much faster and way easier.

Go to BIM Library

Specification

Technical data

Effective width	1157 mm
Total width	1202 mm
Thickness of steel sheet	0,5 mm
Total profile height	51 mm / 56 mm / 66 mm
Rib height for the module 350	25 mm / 30 mm / 40 mm
Rib height for the module 400	25 mm
Module length	min. 1110 mm / max. 6010 mm
Weight	~ 4,5 kg / m²
Length of an overlap, when separating metal sheets	60 mm
ROOF INCLINATION ANGLE	> 9°
LIST OF MODULAR SHEETS	Download

Coatings and colours

HERCULIT [HC]

ULTIMAT [UTK]

MAT 35 Standard [TK]

POLIESTER Standard [RAL]

ICE COVER ZM [ICep]

Available colours

It is a coating developed in close cooperation with a leading manufacturer of varnishes for the best steel mills in Europe. Many years of studying existing coatings and monitoring customer needs, with particular emphasis on the needs of roofers, have allowed us to condense so many different advantages into one product. HERCULIT is a polyurethanecured polyester with a high resistance to mechanical damage and a thickness of 35 μm.

40-year warranty*
*Detailed warranty conditions are specified in the warranty card.

Available colours

A 35 μm-thick coating that has very high corrosion and UV resistance (RC4/RUV4). Its visual feature is its grained structure. It was inspired by nature and is therefore free of chromium and heavy metals and, as an environmentally friendly product, is at least 80% recyclable. Sheet coated with the ULTIMAT [UTK] flexible coating can be profiled at extremely low temperatures.

Warranty period: 20 years*
* Detailed warranty conditions are specified in the warranty card.

Available colours

Matte organic coating with a thickness of 35 μm, which is characterized by high resistance to mechanical damage. A metallic zinc layer on both sides (275 g/m2) provides protection against corrosion and discoloration caused by sunlight.

• Warranty period: 15 years *
* Detailed warranty conditions are specified in the warranty card.

Available colours

Basic organic coating with a thickness of 25 μm. The surface is uniform, smooth – shiny or metallic. A material with a very wide range of applications. It is available in a wide range of colours described by means of a universal RAL chart.

Warranty period: 10 years *
* Detailed warranty conditions are specified in the warranty card.

Available colours

Thick (35 μm) organic coating with an interesting crystalline texture, resembling thickly applied paint. The core is zinc alloy coated steel that provides enhanced protection against corrosion. The result is a significant increase in resistance to white and red corrosion in RC3 environments.

Warranty period: 35 years *
* Detailed warranty conditions are specified in the warranty card.
